? EMIfilters on all Data and Power lines
? Dualpressure control and Lid down sensor for safety
Specification
Shielding Isolation: >75dB,800MHz~6GHz
Inner Dimension: (L)400 (W)400x (H)280 mm
Outer Dimension: (L)530 x(W)605 x (H)330mm
Weight: approx.35kg
Operation temperature: 0 ~ 50 ℃
I/O Connectors
1. 1 DB9(m) outside and DB9(f) inside
2. 1 RJ-45 outside and insider
3. 1 AC(C13) outside and AC (C14) inside, 10 Ampsmax
4. 1 USB 2.0 type A(f)
5. 1 DC(2.0) Power Jack outside and DC (2.0)Power
Jackinside 100VDC, 3Amps max
6. 6 SMA(f) outside and SMA(f) inside
